Made entirely of 6Al-4V gr. 5 titanium, Canine is a subcompact 9mm suppressor of tubeless construction that can be wet or dry, and is light enough to eliminate the need for a booster*. The Alpha pattern threads in the rear will accept 1.125-28 threaded mounts and adapters, including 3 lug and Griffin Cam Lok**. Canine comes standard with an ultralight 7075-T651 direct thread mount in your choice of 1/2-28 or M13.5×1 LH (specify thread in note when ordering).
Despite it’s small size and scant weight, Canine is not delicate like other subcompact 9mm cans and does not have any gel wipes or other wearable parts that will need replacement. Run it hard on your pistol or carbine!
Rated for: .380 ACP, 9x19mm, .38 Special, .357 magnum, .350 Legend subsonic
Full Auto Rated: Yes, keep suppressor under 800°F
Minimum Barrel Length: None with service pistol cartridges, 16″ with .350 Legend subsonic or .357 Magnum
Length (Inches): 4″, 4.3″ with included mount.
Weight (Ounces): 3.1 oz with included mount
Attachment: 1.125-28 Alpha compatible
Distance from rear face to blast baffle tip: 1.03″
Suppression: ~22 dBA Dry
Build Materials: 6Al-4V gr. 5 titanium
User Serviceable: No
Finish: bead blasted natural or Norrell’s Moly Resin in SOCOM black, gloss black, grey-black Colt flat, burnt bronze, Coyote brown, flat brown, OD green or tan FDE
Canine ships with a pin wrench for the mount and a 3cc syringe with a 4″ 14 ga. blunt tip luer lock needle for ablative application. 1-1.5cc is the recommended amount of ablative.
Use of cast lead bullets is not recommended with sealed suppressors. However, Canine can be cleaned with harsh chemicals that dissolve lead. Be sure to remove the aluminum mount first before submerging in solutions that are not aluminum safe.
*We have not tested all possible host & ammunition combinations. Some pistols may need more energetic loads with a rigid mounted suppressor, and there are some hosts that simply don’t like to run suppressed, with or without boosters. We cannot guarantee function of all host firearms, only that all of ours have functioned with Canine using subsonic ammunition, and it is known in the industry that 4-5 ounces is the approximate limit for weight of a suppressor on most locked breech handguns to cycle without the use of a recoil booster. Hammer fired hosts tend to be more tolerant of added mass than striker fired, though all of our personal and demo striker fired weapons have been reliable with Canine using common .380 ACP and 9x19mm subsonic ammunition, including the tiny Diamondback DB380.
**The added mass of some mounts or adapters may cause the assembly to be too heavy for reliable cycling on short recoil pistols.
Foliage Green, Light Grey Flat, Burnt Bronze, Coyote Brown, Tan FDE, SOCOM Black, Grey-Black Colt Flat, OD Green, Flat Brown
