Gyrex Adapter

$69.00$95.00

Clear

Description

Gyrex is a robust taper mount system for suppressors, designed with a large taper interface to provide postive retention and consistent alignment for point-of-impact repeatability every time you reinstall your suppressor on the host.     Additionally, we chose a thread pattern than allows for rapid installation and removal at ~4 revolutions.   These adapters are monolithic with all critical features machined in a single set up to ensure the best possible alignment, and are made from 17-4 stainless steel heat treated to H900 temper for a long service life on any host (titanium adapters are made from Gr. 5 6Al-4V titanium)



The Taper and thread pattern for Gyrex are proprietary.  Neither the muzzle devices or adapters are compatible with other taper mount systems.

For Banish 30 Gyrex adapters, see here: https://www.eccomachine.net/product/banish-30-adapters/

Gyrex Taper Mount Brake 1.375-24 Bravo (HUB) and 1.4375-20 adapter specs:
Length: .78″
Flange Diameter: 1.5″
Flange thickness: .2″
Male Thread: 1.375-24, 1.4375-20
Weight: 2 ounces
Gyrex Taper Mount Brake 1.375-24 Bravo (HUB) Long adapter specs:
Length: 1.28″
Flange Diameter: 1.5″
Flange thickness: .7″
Male Thread: 1.375-24
Weight: 2.1/2.4 ounces
Gyrex Taper Mount Brake 1.375-24 Bravo (HUB) Titanium adapter specs:
Length: .78″
Flange Diameter: 1.5″
Flange thickness: .2″
Male Thread: 1.375-24, 1.4375-20
Weight: 2 ounces
Gyrex Taper Mount Brake 1.375-24 Bravo (HUB) Long adapter specs:
Length: 1.28″
Flange Diameter: 1.5″
Flange thickness: .7″
Male Thread: 1.375-24
Weight: 1.1 ounces

Gyrex Taper Mount Brake 1.125-28 Alpha, 1.180-24 & 1.203-28 adapter specs:
Length: .78″
Flange Diameter: 1.37″
Flange thickness: .425″
Male Thread: 1.125-28/1.180-24/1.203-28
Weight: 1.3-1.6 ounces

Custom color options for the adapter flange are no extra charge, but add 5-10 business days to ship time. Color options do not apply to the brake, and are only applied on the flange of the adapters.

Additional information

Weight 6 oz
Dimensions 4 × 4 × 4 in
Moly Resin

Natural 17-4 H900, Burnt Bronze, Coyote Brown, Tan FDE, SOCOM Black, Grey-Black Colt Flat, OD Green, Flat Brown

Suppressor Thread Pattern

1.125-28 (Alpha), 1.375-24 (Bravo, HUB), 1.375-24 Bravo (HUB) TITANIUM, 1.375-24 Long (Bravo/HUB), 1.4375-20 (D Cell), 1.180-24 Gemtech/Liberty/B-Tube, 1.203-28 Dead Air P-Series
