1.125-28 Alpha Ultralight Aluminum Direct Thread Mounts




Created for our ultralight TLX, canine and Caracal models, these 1.125-28 Alpha direct thread mounts made from 7075-T651 aerospace aluminum weigh just half an ounce, and can be used in any suppressor that has 1.125-28 female threads to minimize weight hanging off your muzzle!

All Ultralight Aluminum Alpha direct thread mounts are muzzle registering.  Aluminum mounts are not recommended for high velocity rifle applications.


Ultralight Aluminum Alpha Direct Thread Mount specs:

Material: 7075-T651 Aluminum
Length: .64″
Male thread length: .35″
Flange thickness: .06″
Tail length: .235″
Depth to internal shoulder: .43″
Flange diameter: 1.2″
Weight: .45-.5 ounces
Internal thread: Choose option, all are muzzle registering (“face mount”)
External thread: 1.125-28

Aluminum mounts are designed for a pin wrench of adjustable type or 7/8″ span with pin size 5/32″ (4mm) or smaller that are at least 3/8″ long.

Additional information

Alpha DT Muzzle Thread

Ultralight .578-28 Aluminum, Ultralight 1/2-28 Aluminum, Ultralight 9/16-24 Aluminum, Ultralight M13.5×1 LH Aluminum, Ultralight M16x1 LH Aluminum

Moly Resin

Foliage Green, Light Grey Flat, Natural, Burnt Bronze, Coyote Brown, Tan FDE, SOCOM Black, Grey-Black Colt Flat, OD Green, Flat Brown
